Conductor: bare copper, tinned copper
Isolante: borracha de silicone
Rated volt: 3000V
Test voltage: 3000V: 9000V. 5Min
Rated Temp.: -60℃～+180℃
Aplicação
JGG high voltage silicone rubber motor lead wires are used where high flexibility is required and in high temperature conditions. It is therefore a suitable connection cable for home
electric appliance, high voltage machines like transformers, generators, motors, traction machines.
| Size | Conductor | Insulation thickness | Cable OD | Resistance | ||
| stranding | OD | Nominal | Nominal | Toler. | Ω/KM | |
| mm² | No/mm | mm | mm | mm | mm | Max. |
| 0.75 | 24/0.20 | 1.14 | 2.0 | 5.14 | ±0.20 | 26.7 |
| 1.0 | 32/0.20 | 1.32 | 2.0 | 5.32 | ±0.20 | 20 |
| 1.5 | 30/0.25 | 1.60 | 2.2 | 6.0 | ±0.25 | 13.7 |
| 2.0 | 41/0.25 | 1.84 | 2.2 | 6.24 | ±0.25 | 9.9 |
| 2.5 | 49/0.25 | 2.00 | 2.4 | 6.8 | ±0.25 | 8.21 |
| 4 | 56/0.30 | 2.60 | 2.4 | 7.4 | ±0.25 | 5.09 |
| 6 | 84/0.30 | 3.60 | 2.6 | 8.8 | ±0.25 | 3.39 |
| 10 | 84/0.40 | 4.60 | 2.6 | 9.8 | ±0.25 | 1.95 |
| 16 | 126/0.40 | 5.70 | 2.8 | 11.3 | ±0.25 | 1.24 |
| 25 | 196/0.40 | 7.1 | 2.8 | 12.7 | ±0.30 | 0.795 |
| 35 | 276/0.40 | 8.5 | 2.8 | 14.1 | ±0.30 | 0.565 |
| 50 | 396/0.40 | 10.3 | 3.0 | 16.3 | ±0.30 | 0.393 |
| 70 | 360/0.50 | 12.40 | 3.0 | 18.4 | ±0.30 | 0.277 |
| 95 | 475/0.50 | 14.50 | 3.2 | 20.9 | ±0.40 | 0.21 |
| 120 | 608/0.50 | 16.00 | 3.2 | 22.4 | ±0.40 | 0.164 |
| 150 | 756/0.50 | 18.00 | 3.5 | 25.0 | +0.60 | 0.132 |
| 185 | 925/0.50 | 20.00 | 3.5 | 27.0 | +0.60 | 0.108 |
| 240 | 1221/0.50 | 23.00 | 3.5 | 30.0 | +0.60 | 0.0817 |
Propriedades mecânicas
Tensile strength: 5N/mm2 min.
Elongation at break of insulation: ≥150%
Min. bending radius: 7×OD
Caraterísticas
JGG high voltage silicone rubber motor lead wire has very good flexibility and good performance of resistance to high temperature, range from -55℃ up to 180℃.
The use of silicone
rubber, a high grade corona resistant insulation material, gives the cable excellent dielectric strength.
